The APD1100 plate diffuser is a fine-bubble aeration element whose rectangular body allows denser floor coverage than disc diffusers. It offers 0.20 m² effective area on a 185×1070 mm membrane surface with a 2-25 m³/h capacity range. EPDM and silicone membranes are available. It is preferred for deep activated-sludge tanks, plants with diurnal load swings and biological aeration ahead of MBR, delivering higher air capacity per connection point.

Bursa

Aquaflex

ATD-63 Fine Bubble Tube Diffuser

The ATD-63 tube diffuser is a fine-bubble aeration element with a 63 mm cylindrical body that mounts directly on the air distribution pipe. It suits narrow and deep tanks without a separate floor grid. Membrane options are EPDM, silicone, PTFE and HTPU; capacity is 0-40 m³/h and effective area 0.05-0.2 m². Suitable for partial grid upgrades, chemically aggressive industrial wastewater and plants planned for staged capacity growth.

Bursa

Acrotech

Filtered Electrostatic Powder Booths

ACROTECH filtered electrostatic powder booths work by powder sticking to the filter under fan suction. German HV filters hold particles down to 10 microns. Automatic pulse valves knock powder back into the booth; it is sieved under the booth and returned to the gun. Paint recovery is stated up to 95%. Standard filter size Ø320×600 mm, 10 m² per filter, radial suction fans and automatic reverse-pressure pulsing are listed.

Kocaeli̇

Top industrial zones

Ikitelli Organized Industrial Zone İstanbul 5 companies Beylikduzu Organized Industrial Zone İstanbul 4 companies Baskent Organized Industrial Zone Ankara 3 companies Antalya Organized Industrial Zone Antalya 3 companies

Products in This Category

Approved supplier product catalogs in this category.

Product type: 92 products

Aquaflex

9" Fine Bubble Disc Diffuser

Bursa

Aquaflex

APD1100 Plate Diffuser

Bursa

Aquaflex

ATD-63 Fine Bubble Tube Diffuser

Bursa

Acrotech

Filtered Electrostatic Powder Booths

Kocaeli̇

Acrotech

Cartridge Dust Collection Systems

ACROTECH dust collection systems filter process dust and particles at high efficiency. Filtration capacity is stated up to 99.9%; they also recover coating material. Cartridge units and cyclones catch all particle sizes. Cartridge collectors are listed with 99.9% efficiency, self-cleaning filters and coating recovery. The FAQ recommends a cartridge filter booth (98–99% recovery) when running one or few colours.

Kocaeli̇

Acrotech

Cyclone Dust Separator Systems

Cyclone Systems Product

The ACROTECH cyclone recovers more than 96% of inlet powder by centrifugal force. Dirty air enters the body and spirals down; particles are thrown to the wall. Clean air leaves up the centre tube. An automatic sieve under the cone recovers powder for reuse. Outlet direction is set by a damper. ATEX suitability for potentially explosive dust is stated. In cyclone booths, extracted powder particles are flung into the cyclone body by a 180-degree centrifugal spin.

Kocaeli̇

Havak

GRINDEX Grinding Dust Extractors

GRINDEX is made for dry grinding and tool sharpening, and for places where incandescent particles could damage filters. A water pre-separator extinguishes sparks before they reach the filter, cutting fire risk and pocket blinding. A manual mechanical shaker keeps efficiency. Extracted air can be returned to the room. Noise is about 70 dBA. High-permeability polyester pockets reach 95% efficiency, up to 99.99% in special duties. DF1 0.75 kW / 1450 m³/h; DF2 2.2 kW / 2280 m³/h.

İstanbul

Havak

Stationary Filter Units (IPERJET DF)

IPERJET DF is fitted with horizontal cartridges for welding fumes, fine and coarse dust, small particles and fumes from thermal cutting. It is for indoor use. Where local rules allow, filtered air can be returned to the room to save energy. A separator zone at the inlet drops most dust into the first tank; remaining dust is filtered into a second tank. The onboard high-performance fan runs at high suction and low noise. DF4 2200 m³/h, DF6 4000 m³/h, DF9 6500 m³/h; cartridges Ø325 × H750 mm, IFA/BGIA M PES polyester.

İstanbul

Havak

AIRALT Dust Collectors

Dirty air enters the hopper; with a sudden speed drop and a first-stage impact filter, large particles fall into the dust bin. Fine particles pass to the cartridges (AIRALT) or bags (AIRALT/M); air flows outside-in and dust collects on the outer surface. Jet-pulse cleaning blows compressed air inside-out. Standard cartridges/bags are IFA/BGIA L-PES polyester. At 0.056 m/s/m², 200 mg/m³ inlet loading and 0.2–2 μm particles, residual is

İstanbul

Ünveren

RP Modular U-TEX Cartridge Dust Collectors

UAS® RP modular U-TEX dust collectors are added together to reach the required capacity. Standard filters are U-TEX PTFE-coated cartridges. Units work by surface filtration and collect dust and emissions. Dirty cartridges are cleaned automatically by compressed-air nozzles with electronic sensing. Standard models: RP-2 2600 m³/h / 35 m² / 3 kW through RP-8 10400 m³/h / 140 m² / 15 kW. Dust bin 100 litres. Compressed air 6 bar – 80 l/min. Used on laser-plasma cutting tables, foundry, automotive, welding, metal polishing and blasting.

Adana · Adana Haci Sabanci Organized Industrial Zone

Ünveren

Wall-Mounted Auto-Clean U-TEX Filter Units

Wall-mounted auto-clean U-TEX units work by surface filtration. Cartridges are PTFE-coated so dust is separated before it enters the media. The system is intended for welding-fume extraction. Cartridges are cleaned automatically with compressed air through rotary blowers. Cleaned air is returned to the room at 99.9%. One-arm model: 2,200 m³/h fan, 1,200 m³/h capture, 1.5 kW. Two-arm: 3,000 m³/h fan, 2×1,000 m³/h, 3 kW. Arms from 2 to 10 m can be fitted. Production of wall-mounted stationary welding-smoke filters started in Turkey in 1992.

Adana · Adana Haci Sabanci Organized Industrial Zone

Ünveren

HCM-55 Filtered Grinding-Welding Tables

Welding Tables Product

The U-TEX cartridge cleans dirty air at 98% and returns it to the work area. A flame-arresting pre-filter and a washable metal filter form a three-stage spark trap before the filter chamber. Operation is surface filtration. Cartridges are pulse-cleaned at 6 bar. The S235JR steel grate is hot-dip galvanized to DIN 24537 and DIN EN ISO 1461. Fan 5000 m³/h, motor 5.5 kW 3000 rpm, 67 dB(A), max load 1000 kg, size 900×1500×900 mm. Uses: welding, grinding, deburring, polishing, blasting, plasma cutting.

Adana · Adana Haci Sabanci Organized Industrial Zone

Services in This Category

Approved supplier service catalogs in this category.

Service type: 13 services

Acrotech

Dust Collection System Design

Project-specific dust-collection design and quotation is offered on the site. Powder and wet-paint coating systems are designed per customer. As an engineering manufacturer Acrotech designs and builds powder plants, wet-paint plants, pretreatment lines and complete painting systems. FAQ: cartridge booth for one or few colours; cyclone booth (5–15 min colour change) when more than 5–6 colours per day.

Kocaeli̇

Havak

Industrial Ventilation Engineering

Engineers analyse customer needs, offer solutions, or survey on site and produce project-specific solutions. In 2015 Havak took the Turkey distributorship of Italian Coral industrial dust collectors. Coral has made fume and dust extraction, filter units, exhaust extraction, high vacuum and ATEX equipment in Italy since 1958. TAI Ankara used a Coral Airalt ATEX industrial dust collector.

İstanbul

Ünveren

Project and Technical Support

The contact page lists [email protected] and [email protected]. The about page states that the professional staff answers customer questions and requests quickly. The factory is 15 minutes from Adana airport and 40 minutes from the international port; road, air and sea freight are possible. Export countries exceeded 52 in 2021.

Adana · Adana Haci Sabanci Organized Industrial Zone

Vanterm

Process-Focused Filtration Engineering

With its passionate technical team, VANTERM provides a high level of engineering to find the best solution for filtration problems. VANTERM always creates a dedicated solution for the dust–fume problem: a product designed for the typical features of that process, called Process Focused Filtration Solutions. Work is done with specialist engineers and production-test facilities.

Kocaeli̇ · Gebze Organized Industrial Zone

General Filter Havak Filtre

Filtration Engineering and Product Support

About states that product support and engineering applications with experienced engineers and specialists are part of the company’s activity. Technical knowledge on filtration and IAQ is shared with customers and with civil-society, chamber and association memberships. Selection of ISO 16890 coarse/fine and EN 1822 HEPA classes and production to European standards is in that engineering scope. The mission text defines manufacture and service of air filters and filter equipment for space ventilation as the activity.

İstanbul

General Filter Havak Filtre

R&D and Product Development

According to About, General Filter Havak gives priority to R&D and, with experienced engineers and specialists at every stage from R&D and planning through production, sales and delivery, is among the sector’s leaders in product support, product development and engineering applications. The ISO 16890 and EN 1822 product family is the output of that development. The company states it believes in transferring knowledge by training new engineers for the sector.

İstanbul

Ulpatek Filtre

Filtration System Engineering

ULPATEK aims to meet filtration demand from simple AHUs to high-quality cleanrooms. FFU laminar cabinets are published as ceiling-hung or floor-standing with EC/AC fans and speed control.

İstanbul

Alperen Mühendislik

Survey, design and manufacture

About: Alperen carries out survey, briefing, design, quotation, manufacture, installation, commissioning and service. The electrostatic-filter page says specialist engineers prepare a detailed offer for the air-cleaning unit based on the need, then manufacture it at the Istanbul factory after approval. Free consultancy is offered for food or industrial-plant ventilation. Custom-order manufacture is listed on the About product list.

İstanbul · Beylikduzu Organized Industrial Zone

M.G.T. Filtre San. ve Tic. A.Ş.

Filtration System Engineering

Filtration system design and engineering for HVAC and industrial applications.

Teki̇rdağ · Cerkezkoy Organized Industrial Zone

Onay Filtre Makina Sanayi ve Ticaret Ltd. Şti.

Filtration Engineering

Plant-specific filtration engineering.

Çorum · Corum Organized Industrial Zone

Mikropor Makina Sanayi ve Ticaret A.Ş.

Filtration Engineering

Application-specific filtration engineering.

Ankara · Baskent Organized Industrial Zone

Dusttek Endüstriyel Toz Toplama ve Filtrasyon Sistemleri

Dust Collection Engineering
