Ankara — Special Machinery (Industrial Machinery)

Aspar Asansör Aksamları Pazarlama San. Tic. A.Ş.

OSG HS Bi-Directional Overspeed Governor

Special Machinery

OSG HS is Aspar’s bi-directional overspeed governor in the elevator safety-equipment class. For type OSG HS the minimum rated speed is 2 m/s and the maximum rated speed is 3 m/s; the minimum sheave diameter is Ø300 mm and the rated rope diameter dnom is 6-8 mm. Bearings are double sealed ball bearings; travel direction is up and down. The governor is safety equipment under Lift Directive 2014/33/EU and complies with EN 81-20/50. Technical details are published in the company’s user-manual PDF.

Ankara · OSTIM Organized Industrial Zone

Ay Yayları

Standard Model Cleaning Basket

Special Machinery

The standard model basket is used on flat facades without recesses. Basket load capacity is 240 kg and self-weight is 270 kg. Two 1 kW motors provide vertical travel; Ø8 galvanized steel rope is used and excess rope is wound on a drum. The door group is steel box profile; other parts are aluminum. The basket has two safety (blockstop) brakes, two overload switches, four upper switches and two lower level switches; vertical and roof machine movements are controlled from inside the basket.

Ankara

Ay Yayları

Pantograph Basket

Special Machinery

Designed to deliver personnel into facade recesses, typically used for recesses of 2 m and above. It opens hydraulically like scissors to extend the basket into the recess; balance is maintained by counterweights opening in the opposite direction. Safe access for recesses from 2 m to 5.5 m. Load capacity 240 kg; basket weight 980–1300 kg depending on opening length. Uses Ø10 6×19 galvanized rope and two 1.5 kW motors rated 1500 kg; hydraulic opening is manual or electric.

Ankara

Ay Yayları

Rotating Basket

Special Machinery

A second platform on the basket can rotate 90 degrees around its axis to deliver personnel into facade recesses. Used for recesses between 2 m and 4 m, preferred when recess depth is the same on all facades. Load capacity 240 kg, basket weight 400 kg. Two 5 kW motors provide vertical travel; Ø10 galvanized steel rope is used with excess wound on a drum. Door group is steel box profile; other parts aluminum; safety brakes and load/upper/lower switches are standard.

Ankara
