Tanpera A.Ş.
Gasketed Plate Heat Exchanger
Plate Heat ExchangerTanpera Gasketed Plate Heat Exchangers increase the heat transfer coefficient through turbulence on the plate surfaces while delivering high capacity in compact dimensions. Gasketed or welded design options are selected according to fluid compatibility and operating pressure. Plates are typically manufactured from AISI 304 or AISI 316 stainless steel; for aggressive fluids, titanium or special alloys are used. Gasket materials are selected as EPDM, NBR, or Viton according to fluid temperature and chemistry. Thanks to the modular plate pack, capacity can be increased or reduced in a controlled manner on site. Applications include HVAC, food and beverage pasteurization, chemical and petrochemical processes, and energy recovery.
İstanbul
Tanpera A.Ş.
Buffer Thermal Balance Tank
Process / Storage TankA buffer thermal balance tank adds water volume to a cooling circuit and reduces temperature swings. Tanpera BF tanks are delivered in the 100–5000 litre range, insulated and with flanged connections. The shell is carbon steel or stainless steel; insulated models minimise heat loss. In chilled-water applications the tank increases system water volume; a baffle plate matched to the volume supports homogeneous distribution and air separation. It provides hydraulic balance on chiller and heat-pump circuits and is recommended for data-centre cooling, central chiller plants, and industrial process cooling. Delivered with an insulated shell and double-layer anti-corrosion protection.
İstanbul
Related products
Adess Group
Heat Transfer Equipment
General Heat ExchangersShell and tube heat exchangers, water bath heaters and air-cooled heat exchangers (ACHE) for oil and gas, petrochemical, power and industrial applications. Equipment is designed according to process conditions such as pressure, temperature, flow rate and required thermal performance. Fabrication includes TEMA R, C and B class designs, ASME Section VIII Div. 1 plus U Stamp, PED 2014/68/EU and CE, shell-and-tube, U-tube and fixed tubesheet types, tube-to-tubesheet expansion and welding, HTRI thermal and hydraulic design software, and pickling and passivation with citric, nitric and phosphoric acid. Shell-and-tube units are offered as fixed tubesheet, floating tubesheet and U-tube; water bath heaters heat natural gas and other process fluids indirectly; ACHE units can be designed to ASME and API 661 with finned or bare tube bundles, plug or cover-plate headers and fan and drive systems. Materials include carbon steel, stainless steel, nickel alloys, copper alloys and duplex and super duplex.
Teki̇rdağ · Ergene-1 Organized Industrial Zone
Konuk Isı Mak. San. ve Tic. Ltd. Şti.
Air Cooled Heat Exchangers
General Heat ExchangersKonuk Isı air-cooled heat exchangers are designed for severe service; each part is reviewed by engineering, welding and quality staff. The package comprises finned-tube bundles, fan stacks, driven axial fans and a steel structure; walkways and louvers can be added. L-fin wraps an aluminium strip in an L shape onto the tube, with a maximum operating temperature of 150 °C. Extruded B-fin aluminium tubes are rated to 300 °C and embedded G-fin to 400 °C. Welded bonnet headers have a maximum design pressure of about 100 bar; removable-cover headers allow cleaning and maintenance. Aluminium fins are light and corrosion resistant; galvanized steel tubes add mechanical toughness.
Teki̇rdağ · Velimese Organized Industrial Zone
Konuk Isı Mak. San. ve Tic. Ltd. Şti.
Closed Circuit Cooling Tower
General Heat ExchangersIn a closed-circuit cooling tower the process coolant flows through a galvanized, stainless or copper tube coil; spray water and axial fans reject the heat. Isolating the process fluid from ambient air keeps contaminants out and reduces cleaning. Coils are pneumatically leak-tested underwater at 15 bar to PED 97/23/EC and then hot-dip galvanized. The structure uses Z-725 g/m² hot-dip galvanized steel. Fans have adjustable extruded aluminium blades; motors are 1.1–45 kW, 4/6/8 pole, IP55–IP65, 400 V standard. Free-cooling in winter and inverter control of pumps and fans cut energy use.
Teki̇rdağ · Velimese Organized Industrial Zone
Barış Endüstriyel Enerji Sistemleri A.Ş.
Economizers
General Heat ExchangersEconomizers are energy recovery equipment designed to increase efficiency in industrial applications such as steam, hot water and thermal oil boilers. Waste heat in flue gases is recovered to reduce fuel consumption. Approximately every 21 °C drop in flue gas temperature means about 1% fuel savings.
Adana · Adana Haci Sabanci Organized Industrial Zone
